Technical Specifications of Coach:
| Model | XMQ6112AY |
| Driving(LHD/RHD) | LHD |
| TECHNICAL PARAMETERS | |
| Body structure | Semi-integral |
| Length*Width*Height (mm) | 10990*2500*3580 |
| Maximum speed（km/h） | ＞100 |
| Gradeability（%） | ＞30% |
| CAPACITY | |
| Seats | 49+1+1 |
| Maximum passenger capacity | 51 |
| CHASSIS | |
| Fuel tank capacity (L) | 360 |
| Engine（Hp） | 310 |
| Transmission | Manual |
| Suspension system | Front 2 Rear 4; Air Suspension |
| Front Axles（T） | 5.5 |
| Rear Axles（T） | 11 |
| ABS | ABS |
| Brake system (Disc/Drum) | Front: Disc; Rear: Drum |
| Steering system | Power steering |
| Tire | 11R22.5 |
| Electromagnetic fan | Mechanical/Electromagnetic Clutch |
| Body lifting device | Without |
| BODY | |
| Doors | Aluminum, remote control,outward-opening |
| Side windows | ● Tempered glass◎ Double glazed |
| Driver seat | ● Air-dampened, adjustable◎ Mechanical dampened, adjustable |
| Passenger seats | Adjustable passenger seat with high back |
| Mirror type | Wide view electric rear view mirrors ( with defroster) |
| OTHER CONFIGURATION | |
| Air conditioner（KW） | ● 32000 Kcal/h ◎ 34000 Kcal/h |
| Heating and defrosting states | ● Defrosting from engine heat source ◎ With independent heater |
| Electrical instrument | ● CAN Meter ◎ CAN System |
| Automobile data recorder | ● With tachograph◎ Without tachograph |
| Player | ● Hard Disk Player ◎ DVD Player |
| Middle door and back-up monitor | ● LCD Monitor |
| Guideboard | ◎ Route Display |
| NEW TECHNOLOGY | |
| On-board computer | Without |
| 360 panoramic view | ◎ |
| EPB | ◎ |
| Note: ● standard specification; ◎ optional specification; ※ special clarification; those without symbols are standard specification | |
 | |||
 |  |  |  |
 |  |  |  |
 |  |  |  |
 |  |  |  |
King Long has four major production bases: Xiamen Large & Medium-Sized Bus Production Base, Xiamen minivan Production Base, Xiamen Special Vehicle Production Base and Shaoxing Special Vehicle Production Base, providing the most complete range of intelligent transportation products in the industry, including large and medium buses, minivans, autonomous buses and chassis, special vehicles, trucks, RVs, mobile hospitals, various travel products and solutions. For 13 consecutive years, King Long has ranked first in the industry in terms of overseas export volume, exporting nearly 140,000 buses to nearly 150 countries and regions around the world.
