14 Seater Electric Sightseeing Bus DN-14B TRAIN

Electric Sightseeing Bus Features

1. Arractive design and powerful in appearance, with strong carrying capacity and lower noise;

2. Standard feature: Front and Rear lights; Rear View mirrors; Electric Horn; Rustproof body structure;

3. Small turning radius; and smart steering system; Whole style steel rear axle;

4. Can be easy modified to transportation vechicles;

5. CE certificate for whole carts;

6. Import main parts: Maintenance free batteries and Curtis controller(From USA);

7. Four wheels hydraulic braking system and independent parking brake.

Electric Shuttle Bus Specifications

Battery	Leoch maintenance-free battery 6V*12 PCS	Minimum  turning  radius  (m)	6.5
Motor	AC 72V  7.5KW	Max.  climbing  ability  (loaded)	20%
Controller	72V400A	Overall  dimensions(mm)	5050*1500*2200
Charger	On board charger	Max.  loading  weight(kgs)	1200
Suspension:	Macpherson  strut  suspension	Net  weight(kgs)	1300
Steering	Rack&Pinion  steering	Chassis	Steel
Braking  system	Four  wheels  hydraulic  braking  system	Wheelbase(mm)	2700
Passenger  capacity	14	Ground  clearance(mm)	130
Range (loaded) (km)	60 km	Tires:	165/70R  13
Max.  speed  (km/h)	28	Quantity  per  Container	1pcs  /  20ft.  2pcs  /  40HQ

Electric Shuttle Bus Configuration

STANDARD  CONFIGURATION:
DESCRPTIONS	REMARKS
seats belts	3 points for driver, 2 points for other passengers
wiper	wiper
speed meter	speed meter, battery indicator,voltmeter, current-meter,
rear view mirrors	rear view mirrors
front and rear light	Full lights system
Body	Fiber glass body
Roof	Steel Frame + fiber glass cover
Windshield	One-piece see-through laminated windshield
Beverage holders	1 pcs cup drink holders
STANDARD  CONFIGURATION:
DESCRPTIONS	REMARKS
Body	Fiber glass body
Roof	Steel frame + fiber glass cover
Windshield	One-piece see-through laminated windshield with wiper
lights system	front lights, tail lights, turing lights, brakelights, fog lights
mirrors	side mirrors, inner mirror
Dashboard	speedometer combined with batterycapacityindicator,hours  meter, current meter, voltage meter,rangemeter
OPTIONAL CONFIGURATION/ACCELERATORS:
Trojan battery, AC electric system 72V, Full enclosure weather curtains, Sunshade Curtain,Seat belts, Loud speaker, CD player, Solar panel on top, Aluminum rim wheels, Front discbrakes,rear wheel drum brakes
