Battery Charger LC-2256 Series
Car Battery Charger Features1. It is suitable for charging and maintaining 6V and 12V lead-acidbatteries and 12V lithium iron phosphate batteries;
2. Suitable for all kinds of motorcycles, automobiles, toy cars, scooters, battery cars, charging, and maintenance
3. The charging current of this series of chargers can choose 2A(LC2256), 3A(LC-2257), 4A(LC-2258)
4. Different charging rates can be selected according to the battery capacity. Suitable for lead-acid batteries with a capacity of 3AH-50AH
5.Support 0V ultra-low battery voltage to start charging, intelligent control pulse, and high-voltage mode to activate the vulcanized battery, which can effectively repair and maintain the deeply deprived battery.
6.It adopts an MCU microprocessor to control the 5-stage charging mode, charging enough, but not charging
7. The shell adopts an IP65 waterproof design, which is better protected and safer to use.
Battery Charger SpecificationsSPECIFICATIONS | LC-2256 | LC-2257 | LC-2258 |
AC input voltage | 90Vac~132Vac/185Vac~264Vac | 90Vac~132Vac/185Vac~264Vac | 90Vac~132Vac/185Vac~264Vac |
AC input frequency | 47Hz~63Hz | 47Hz~63Hz | 47Hz~63Hz |
AC input power | 40W | 56W | 75W |
Battery voltage is optional | 6V,12V | 6V,12V | 6V,12V |
Battery type is optional | SLA AGM GEL Lithium | SLA AGM GEL Lithium | SLA AGM GEL Lithium |
Charging power | 30 W | 45 W | 60 W |
Charging voltage range | 0~15.5Vdc | 0~15.5Vdc | 0~15.5Vdc |
Charging current | 2A | 3A | 4A |
Charging voltage | 14.7V/7.35V | 14.7V/7.35V | 14.7V/7.35V |
Light switching current | 0.4A | 0.5A | 0.5A |
Float charging voltage | 13.65V/6.8V | 13.65V/6.8V | 13.65V/6.8V |
Efficiency | 85% | 85% | 85% |
Overload Protection | YES | YES | YES |
Short Circuit Protection | YES | YES | YES |
Reverse Polarity Protection | YES | YES | YES |
Operating temperature | 0℃~40℃ | 0℃~40℃ | 0℃~40℃ |
Dimension (mm) | 167*72*40mm | 167*72*40mm | 167*72*40mm |
