Name: FB80 - 8 Ton Electric Forklift (Li-Ion)
Brand: LTMG
SKU: SKU-2443-Q0SXV
Availability: InStock

Email to a Friend

FB80 - 8 Ton Electric Forklift (Li-Ion)

(0 reviews)

$0.00

Sold By:LTMG

It adopts the internal combustion forklift structure, which has been examined by the market for more than 30 years, manifesting the features of high structural strength and high stability.

For the key components, it adopts mature and steady axles of internal combustion forklift, such as driving axle and steering axle. The large market holdings is a powerful guarantee for convenient maintenance and high product quality.

3It adopts Double Gun charging piles as standard confituration, with the charging capacity of 400AH per hour. The high efficiency greatly increases its working hours per day.

It adopts high quality lithium iron phosphate battery, ensuring zero emissions in the entire working process.

Advanced motor drive system with compact structure generates better driving and climbing performance, higher torque and more powerful forces.

SKU:SKU-2443-Q0SXV
Categories:More
Brands:LTMG

Specification

Model		FB80
Rated Capacity	kg	8000
Load Center Distance	mm	600
Power Type		Lithium Battery
Wheel Base	mm	2250
Wheel Number(Front/Rear)		4×/2
Front Tread	mm	1470
Rear Tread	mm	1190
Tyre(Front)		8.25-15-14PR
Tyre(Rear)		8.25-15-14PR
Front Overhang	mm	590
Mast Tilting Angle,Front/Rear		6/12
Height With Mast Retraction	mm	2500
Free Lifting Height	mm	200
Max.Lifting Height	mm	3000
Max.Height After Lifting	mm	4420
Overall Guard Height	mm	2450
Fork Size:Length X Width X Thickness	mm	1220×150×65
Overall Length(Fork Excluded)	mm	3600
Overall Width	mm	1995
Turning Radjus	mm	3370
Ground Clearance Of Mast	mm	200
Ground Clearance Of Wheel Base Center(Loaded)	mm	220
Right Angle Stacking Aisle Width (Pallet 1000×1000Mm），Clearance 200Mm	mm	5195
Right Angle Stacking Aisle Width (Pallet 1200×1200Mm）,Clearance 200Mm	mm	5395
Lateral Fork Adjustment Max./Min	mm	1840-300
Travelling Speed (Loaded/Unloaded)	km/h	13/15
Lifting Speed (Loaded/Unloaded）	mm/s	340/380
Lowering Speed	mm/s	430
Gradeability (Loaded)	%	18
Self Weight	Kg	10600
Battery Voltage /Capacity	V/Ah	76.8/808
Battery Weight	Kg	600
Driving Motor Power-60 Minutes	Kw	30
Lifting Motor Power(S315%)	Kw	2X26
Driving Motor Control Mode		MOSFET/AC
Lifting Motor Control Mode		MOSFET/AC
Service Brake/Parking Brake		Hydraulic /Mechanical
Hydraulic System Working Pressure	Mpa	20.0

With technological innovation our product configuration and parameters will continue to change without notice;

if there is any doubt the specific confirmation of our international trade sales shall prevail;
