Specification
Rated Load | 7000kg | |
Bucket Capacity | 4.2-4.5m³ | |
Operating Weight | 25000kg | |
Rated power | 510kw | |
Dumping Height | 3752mm | |
Dumping Reach | 1479mm | |
Wheel Base | 3700mm | |
Wheel Tread | 2300mm | |
Max. Traction | 195KN | |
Max. Rising Power | 210KN | |
Total Time | 9.7S | |
Lifting Time | 5.8S | |
Dumping Time | 3.5S | |
Max. Climbing Angle | 28° | |
Turning Angle | 40° | |
I/II Forward Gear I/II | 18/36km/h | |
I Reserve Gear I | 18/36km/h | |
Overall Dimensions（L*W*H） | 9782x3007x3587mm | |
Service Brake | Air-jack oil, clamp disc type | |
Hand Brake | Pneumatic control, clamp disc type | |
Air Conditioning System | Electric, heating and cooling | |
System Voltage | DC-24V | |
Tire Model | 26.5-25 | |
Battery Life | 5-7 | |
Charging Time | 60min | |
Power Battery | Type | Lithium battery |
Rated Capacity | 608Ah | |
Store Energy | 350kWh | |
Nominal Voltage | 576V | |
Working Hydraulic System | Type | Double pump confluence |
Operation Method | Pilot control | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
Address: No. 506, Xinglinwan Road, Jimei District, Xiamen, Fujian, CN
With the mission of making the world greener, LTMG has focused on the construction machinery industry for more than 20 years. From R&D and production to reaching global customers, LTMG has always been quality-oriented and excellent service, conveying the power of China's machinery manufacturing to the world
