Specification
Specification | Unit | LTE240EV |
Total weight | T | 24 |
Bucket capacity | M³ | 1.17 |
Motor model | WR510 | |
Rated power | Kw/r/min | 140/1900 |
Rated voltage | V | 618.2 |
Rated stored energy | KWh | 422.8 |
Max displacement | L/min | 260*2 |
Working pressure | Mpa | 34.3 |
Hydraulic pump mode | APVO140TVN90WI | |
Hydraulic tank volume | L | 246 |
Walking speed (high/low) | km/h | 4.2/2.6 |
Swing speed | r/min | 10.3 |
Climbing ability | ° | 35 |
Bucket excavation force | KN | 159 |
Arm digging force | KN | 115 |
Ground specific voltage | KPa | 48.6 |
Traction force | KN | 219 |
Max. excavation height | mm | 9310 |
Max. unloading heigh | mm | 6438 |
Max.excavation depth | mm | 6875 |
Max. verticalarm mining depth | mm | 5860 |
The distance when digging 2.5 horizontal plane | mm | 6680 |
Max. excavation distance | mm | 10170 |
Max. excavation distance on the ground | mm | 9990 |
Min. turning radius | mm | 3975 |
Max. height at minimum turning radius | mm | 7775 |
Distance from the center of rotation to the rear end | mm | 2810 |
Counterweight height | mm | 2120 |
Grounding length during transportation | mm | / |
Overalllength | mm | 9930 |
Overall width | mm | 2980 |
Total heigh(boom top) | mm | 3190 |
verall height(top ofcab) | mm | 3120 |
Counterweight ground clearance | mm | 1065 |
Min. ground clearance | mm | 442 |
Tail turning radius | mm | 3000 |
Track grounding length | mm | 3640 |
Track length | mm | 4450 |
Rail guage | mm | 2380 |
Track width | mm | 2980 |
Track shoe width | mm | 600 |
Turntable width | mm | 2700 |
rack tooth thickness | mm | / |
Arm length | mm | 3050 |
Boom length | mm | 5850 |
With technological innovation our product configuration and parameters will continue to change without notice;
if there is any doubt the specific confirmation of our international trade sales shall prevail;
