Specification
Model | WZ20-28 |
Overall Dimension（L×W×H） | 6200*1960*2800mm |
Wheel Base | 2550mm |
Wheel Tread | 1580mm |
Min. Ground Clearance | 290mm |
System Pressure | 18MPa |
Operating Weight | 5400Kg |
Max. Speed | 28Km/h |
Max. Climbing Gradient | 25° |
Digging Parameters | |
Turning Radius | 4500mm |
Max. Digging Depth | 2600mm |
Max. Digging Dumping Height | 2300mm |
Max. Digging Radius | 4600mm |
Bucket Width | 600mm |
Backhoe Capacity | 0.2m3 |
Max. Digging Height | 4300mm |
Max. Digging Force | 28kN |
Rotary Angle Of Excavator | 180° |
Loading Parameters | |
Max. Dumping Height | 3500mm |
Max. Dumping Distance | 900mm |
Bucket Width | 2100mm |
Bucket Capacity | 1m³ |
Max. Loading Lifting Height | 4300mm |
Max. Breakout Force | 42kN |
Forward Shovel Action Time | 12S |
Engine | Yunnei YN38GBZ |
Rated Power | 76KW |
Rated Speed | 2400r/min |
Cylinders-Inside Diameter | 4-120 |
Gear Shift | F2/ R2 |
Steering Angle | 33° |
Tire Size | 16/70-20 |
Front Wheel Pressure | 250kPa |
Rear Wheel Pressure | 250kPa |
Fuel Tank | 50L |
Hydraulic Tank | 50L |
Drive Type | Four-wheel drive |
Variable Speed Type | Hydraulic variable speed |
Variable Speed Type | 600mm |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
