Drive wheel

4x2

Load capacity

2~3 tons

Engine

Model

WEICHAI POWER WP2.3NQ110E20

Displacement

2.29 Liters

Maximum output

110HP

Emission standard

Euro II

Number of cylinder

4-cylinder in-line with water cooling, turbo-charging and intercooling

Transmission

WLY-MG85, Manual type 5 forward speeds

Clutch

Dry type Ф275mm

Front Axle

DR052 model, 2 tons

Rear Axle

The modified casting axle 130 (rate:5.125), 3 tons

Steering

Hydraulic booster, LHD/ RHD

Brakes

Drum type, with ABS Braking, hydraulic booster type.

Chassis

Frame

150*60*4 mm

Qty. Of leaf spring

F 3/ R (7+3) pcs

Fuel tank

80L Steel tank

Wheel Base

2500mm

Wheel&Tire

4+1 pcs Radial Tire, 6.50R16-10

Driver's cabin

Model, description

Tiger VR, Electric lifting windows,3 seats

Air Conditioner

Yes

Electrics

Operating voltage

 12v

Starter，Alternator

 12v ,China brand

Overall Dimensions

Overall Length

 5102mm

Overall Width

 2080mm

Overall Height

 2260mm

Performance

Max. driving speed

 95 km/h

Cargo Body Dimensions

LxWxH

 3400*1800*410mm

Material & thickness

Carbon steel,bottom 2mm, side 1.5mm
