Specification
Model | FDS30 | ||
Power Type | diesel | ||
Rated Capacity | kg | 3000 | |
Load Centre | mm | 500 | |
Lift Height | mm | 3600 | |
Fork Size (L×W×T) | mm | 1070×125×45 | |
Mast Tilt Angle(F/R) | Deg | 6°/6° | |
Front Overhang | mm | 700 | |
Ground Clearance(Bottom of mast) | mm | 190 | |
Overall Dimension（L×W×H） | mm | 4190×2000×2475 | |
Platform Width | mm | 1200 | |
Platform Length | mm | 4190 | |
Overhead Guard Height | mm | 2475 | |
Turning Radius(outside) | mm | 4250 | |
Travel Speed(Full load) | km/h | 17 | |
Lifting Speed(Full load) | mm/s | 440 | |
Max.Gradeability | % | 20 | |
Tire（Front） | 2×28×9-15-12PR | ||
Tire（Rear） | 2×28×9-15-12PR | ||
Wheelbase | mm | 2580 | |
Weight | kg | 5670 | |
Battery(Voltage/Capacity) | V/Ah | 12/80 | |
Engine | Model | A498BPG-78 | |
Manufacturer | XIANCHAI | ||
Rated output/r.p.m | kw | 45/2500 | |
Rated torque/r.p.m | N·m | 193/1800 | |
No.of Cylinder | 4 | ||
BorexStroke | mm | 98×105 | |
Displacement | CC | 3168 | |
Fuel Tank Capacity | L | 75 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
