Specification
Model |
| LTWP0406 | LTWP0608(mini) |
Maximum working height | m | 6.00 | 8.00 |
Maximum platform height | m | 4.00 | 6.00 |
Safe working load | kg | 230 | 230 |
Safe working load of extension platform | kg | 100 | 230 |
Size of working platform | m | 1.29×0.716×1.13 | 1.67X0.74X1.1 |
Overall dimensions | m | 1.43×0.76×2.063 | 1.85×0.8×2.22 |
Overall dimensions | m | 1.43×0.76×1.655 | 1.85×0.8×1.72 |
Table extension size | m | 0.6 | 0.9 |
Minimum Ground Clearance | m | 0.07/0.015 | 0.083/0.016 |
Wheelbase | m | 1.058 | 1.36 |
Turning radius (inner/outer wheel) | m | 0.4/1.6 | 0/1.64 |
Lifting motor | kw | 24V/0.8 | 24V/3.3 |
Lifting speed | m/min | 4-6 | 3-5 |
Traveling motor | kw | 2×0.4/24V | 3.3/24V |
Traveling speed | km/h | 4 | 3.5 |
Traveling speed of the machine (lifting state) | km/h | 0.8 | 0.8 |
Battery |
| 2×12V/80ah | 4X12V/80AH |
Charger |
| 24V/10A | 24/30A |
Maximum climbing capacity |
| 25% | 25% |
Maximum permissible angle of operation |
| 1.5°/3° | 1.5°/3° |
Tires | mm | Φ230×80 | Φ305×100 |
Weight | kg | 850 | 1650 |
