Specification
Performance Parameters | Unit | LWE150 | |
Operating Weight | Kg | 15000 | |
Engine Model | YUCHAI YC4D115 | ||
Rated Power | Kw | 85KW/2200RPM | |
Bucket Capacity | m³ | 0.6 | |
Max Digging Force | Kn | 91 | |
Swing Speed | rpm | 0-12 | |
Traveling Speed | km/h | 0-28 | |
Gradeability | ° | 25 | |
Operating Range | |||
Max. Digging Radius | mm | 8000 | |
Max. Digging Depth | mm | 4750 | |
Max. Digging Height | mm | 8930 | |
Max. Dumping Height | mm | 6520 | |
Tail Swing Radius | mm | 2420 | |
Max. Blade Dozer Cutting Distance | mm | 100 | |
Max. Blade Dozer Lifting Distance | mm | 400 | |
Overall Dimensions | |||
Overall Length | mm | 7520 | |
Overall Width | mm | 2570 | |
Overall Height | mm | 3425 | |
Mini.Ground Clearance | mm | 350 | |
Undercarriage width | mm | 2570 | |
With technological innovation our product configuration and parameters will continue to change without notice;
if there is any doubt the specific confirmation of our international trade sales shall prevail;
