Car Battery Charger CM61 Series

Car Battery Charger Features

1. 6 and 12 Volt battery charging 1/2/3A charge rates;12. Can be charged for AGM, Gel Cell, Spiral Wound, and Deep Cycle Batteries.

2. Fully automatic operation;12. Can be charged for AGM, Gel Cell, Spiral Wound, and Deep Cycle Batteries.

3. Advanced multi-phase charging process;

4. Properly charges all battery types;

5. Soft Start Mode for severely depleted batteries;

6. Recondition Mode rejuvenates distressed batteries;

7. Enhanced maintenance mode for ideal long term storage;

8. Temperature compensation for more effective charging;

9. Reverse Polarity Protection and Battery Fault Detection;

10. Data rich display provides detailed feedback during charging;

11. Internal Micro Processor Technology - Outputting current only when a proper battery connection has been made;

12. Can be charged for AGM, Gel Cell, Spiral Wound, and Deep Cycle Batteries.

Car Battery Charger Specifications

Product Description	CM61 Series
	6V output			12V output
Output current	1A	2A	3A	1A	2A	3A
Output voltage range	3~15.5 V DC			3~15.5 V DC
Bulk charge current rating	STD7.35+/-0.2VDC			STD14.7+/-0.2VDC
Output power	15.5W	30W	48.5W	15.5W	30W	48.5W
Charging current	1A+/-0.2A			1A+/-0.2A
	2+/-0.2A			2+/-0.2A
	3+/-0.3A			3+/-0.3A
Reconidition rating	7.75+/-0.2V DC			15.5+/-0.2V DC
Float charge rating	6.8+/-0.2V DC			13.7+/-0.2V DC
Light switch current	200mA	400mA	500mA	200mA	400mA	500mA
Input voltage range	90V DC~132V AC			90V DC~132V AC
input voltage rating	100V DC~120VAC			100V DC~120VAC
Input frequency	60Hz			60Hz
Input current	0.3A@120V	0.5A@120V	1A@120V	0.3A@120V	0.5A@120V	1A@120V
Input power(Max)	20W	38W	60W	20W	38W	60W
Operating temprature	-20~45 degree			-20~45 degree
Storage temperature	-30~85 degree			-30~85 degree
Operating relative humidity	8~90%			8~90%
Storage relative humidity	5~95%			5~95%
Indicator status	Green LED on = full charge, Orange LED on = charging
Available protection	Overload, short circuit,reversed polarity protection
