Specification
Model | FT50 | |
Rated Load | kg | 5000 |
Maximum Lifting Height | m | 7 |
Maximum Front Reach | m | 6.8 |
Overall Length (To Fork Carrier) | m | 6.08 |
Overall Width | m | 2.26 |
Overall Height | m | 2.54 |
Wheelbase | m | 3.3 |
Ground Clearance | m | 4 |
Turning Radius | m | 4 |
Weight | kg | 11000 |
Cab Width | m | 0.9 |
Tires | 16/70-24 | |
Fork Size(L×W×T) | mm | 1200×125×45 |
Lifting | s | 7.2 |
Lowering | s | 5.5 |
Extension | s | 6.5 |
Retraction | s | 5.4 |
Upper Tipping (Filling) | s | 2.9 |
Downward Tipping (Unloading) | s | 2.8 |
Engine | ||
Manufacture | YUCHAI | |
Model | YC4DK90-T304 | |
No.of Cylinder | 4 | |
Displacement | L | 3.621 |
Rated Output/r.p.m. | Kw | 73.5 |
Rated Torque/r.p.m. | N.m | 400 |
Number Of Gears | F4/R4 | |
Maximum Speed | km/h | 34 |
Fuel Tank Capacity | ||
Hydraulic Oil | L | 450 |
Diesel Oil | L | 260 |
With technological innovation our product configuration and parameters will continue to change without notice;
if there is any doubt the specific confirmation of our international trade sales shall prevail;
