Specification
Performance Parameters | Unit | LTE18 |
Operating Weight | Kg | 1750 |
Engine Model | Laidong 3TE25 | |
Rated Power | Kw | 18.4 |
Bucket Capacity | m³ | 0.06 |
Bucket Width | mm | 435 |
Max Digging Force | Kn | 11.5 |
System Working Pressure | Mpa | 18 |
Swing Speed | rpm | 10-12 |
Traveling Speed | km/h | 2.8 |
Gradeability | ° | 35 |
Ground Pressure | Kpa | 38 |
Operating Range | ||
Max. Digging Distance | mm | 3860 |
Max. Digging Depth | mm | 2050 |
Max. Digging Height | mm | 3370 |
Max. Dumping Height | mm | 2390 |
Min. Swing Radius | mm | 1720 |
Overall Dimensions | ||
Overall Length | mm | 3800 |
Overall Width | mm | 1050 |
Overall Height | mm | 2280 |
Min. Ground Clearance | mm | 210 |
Track Ground Length | mm | 1050 |
Track Width | mm | 230 |
With technological innovation our product configuration and parameters will continue to change without notice;
if there is any doubt the specific confirmation of our international trade sales shall prevail;
Adresse: No. 506, Xinglinwan Road, Jimei District, Xiamen City, Fujian Province, Xiamen, Fujian, CN
With the mission of making the world greener, LTMG has focused on the construction machinery industry for more than 20 years. From R&D and production to reaching global customers, LTMG has always been quality-oriented and excellent service, conveying the power of China's machinery manufacturing to the world
