Specification
Characteristics | Model | TRS15 | |
Power type | Electric | ||
Operation type | Stand Type | ||
Load capacity | Q(kg) | 1500 | |
Load center | C(mm) | 500 | |
Load distance,centre of drive axle to fork | X(mm) | 155 | |
Wheelbase | Y(mm) | 1435 | |
Reach distance | L(mm) | 600 | |
Weight | Service Weight (with Battery) | kg | 1900 |
Wheels, | Wheel type | PU | |
Drive wheel | の×w(mm) | φ230*75 | |
Front wheel | の×w(mm) | φ210*85 | |
Rear wheel | の×w(mm) | φ150*50 | |
Wheel tread,Front wheel | b10(mm) | 735 | |
Wheel tread,rear wheel | b11(mm) | 945 | |
Dimensions | Mast Height,Lowered | h1(mm) | 1845 |
Lifting height | h3(mm) | 2500 | |
Max.height when lifting | h4(mm) | 3470 | |
Fork face min.ground clearance | h13(mm | 35 | |
Fork tilting angle Front/rear | 3/5 | ||
Body length | 12(mm) | 1715 | |
Overall Length | L1(mm) | 1834/2276 | |
Overall width | b1(mm) | 1034 | |
Fork size | s/e/l(mm) | 35/100/1070 | |
Fork Spread | b5(mm) | 210-680 | |
Min.ground clearance | m2(mm) | 70 | |
Aisle Width for Pallet 1000*1200 crossways | Ast(mm) | 2715 | |
Aisle Width for Pallet 1200*1000 crossways | Ast(mm) | 3116 | |
Min.turning radius(without/with platform) | Wa(mm) | 1752/2153 | |
Performance | Max.travel speed(Unladen/Laden) | km/h | 5/4 |
Lifting speed(Unladen/Laden) | m/s | 0.112/0.092 | |
Lowering speed(Unladen/Laden) | m/s | 0.094/0.115 | |
Max.Grade ability(Unladen/Laden) | % | 8/5 | |
Motor, | Service Brake | Electromagnetic Brake | |
Drive Motor | kw | 1.5 | |
Lift Motor | kw | 2.2 | |
BatteryType | Lead Acid | ||
Battery voltage/nominal capacity | V/Ah | 24/210 | |
Charger | V/A | 24/30 | |
Other | Type of drive control | AC | |
Sound level at the driver's ear acc.to EN12053 | dB(A) | 75 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
