Technical data of FEP15

1.2

Model

FEP15

1.3

Power unit

Electric

1.4

Operation

Pedestrian

1.5

Rated traction weight

Q (t)

1.5

1.6

Load centre

c (mm)

600

1.8

Axle centre to fork face

x (mm)

944

1.9

Wheel base

y (mm)

1243

Weights

2.1

Service weight with battery

kg

142

Wheels/Tyres

3.1

Wheels type

PU

3.2

Driving wheel size

Φ×w(mm)　

Φ210×70

3.3

Bearing wheel size

Φ×w(mm)　

Φ80×60

3.4

additional wheels（dimensions）

Φ×w(mm)　

Φ50×30

3.5

Wheels, number front/rear (x = driven)

1x/4

3.7

Track width

b₁₁ (mm)

400/535

Dimensions

4.4

Lift

h3 (mm)

200

4.9

Overall height(With handle

h₁₄ (mm)

740/1160

4.15

lowered hength

h₁₃ (mm)

85

4.19

Overall length

l₁ (mm)

1603

4.20

Length to fork face

l2 (mm)

453

4.21

Overall width

b₁/ b₂ (mm)

550/685

4.22

Fork dimensions

s/e/l (mm)

50/150/1150

4.25

Width of forks

b5 (mm)

550/685

4.32

Min.Ground clearance

m₂ (mm)

35

4.33

Aisle width with pallet 1000 x 1200 across forks

Ast (mm)

1804

4.34

Aisle width with pallet 800 x 1200 along forks

Ast (mm)

1854

4.35

Min.Turning radius

Wa (mm)

1398

Performance

5.1

Travel speed,laden/unladen

(km/h)

4.2/4.5

5.8

Maximum climbing ability, with/without load

(%)

5/10

5.10

Service brake

Electromagnetic

Drive

6.1

Drive motor, 60 minute rating

(kW)

0.75

6.2

Lift motor rating at S3 15%

(kW)

0.8

6.3

Battery according to DIN 43531/35/36 A,B,C,no

no

6.4

Battery voltage/rated capacity

(V/Ah)

24/20

24/30

24/40

24/60

6.5

Battery weight (± 5%)

(kg)

6

7.8

10.2

13.2

Others

8.1

Type of drive control

DC

8.4

Noise level at operator‘s ear

(dB(A))

≤70

10.5

Mechanical
