Optional colors | red, blue, green, yellow, grey,silver |
L×W×H(mm) | 2942×1180×1370 |
Cargo Box size(mm) | 1500×1100×330 |
Wheel base(mm) | 2000 |
Wheel track(mm) | 950 |
Minumum ground clearance(mm) | ≥150 |
Minimum turning radius(m) | ≤4 |
Curb weight(kg) | 231 |
Rated load (kg) | 300 |
Max speed(km/h) | 25/35 |
Grade ability(%) | ≤20 |
Battery | 72V45AH |
Motor, Controller(w) | 72V1000W |
Range per charging(km) | 50-60 |
Charging time(h) | 6-8h |
Front shock absorber | Φ37 Drum shock absorber |
Rear shock absorber | 50×105 Five pieces leaf spring |
Front/Rear tyre | 3.5-12/4.00-12 |
Rim type | steel |
Handlebar type | ● |
Front/Rear brake type | Frontc/Rear:Drum |
Parking brake | Hand brake |
Rear axle structure | Integrated rear axle |
Vehicle lamps | Normal light (48V) |
High and low speed function | ● |
reversing light | ● |
LCD meter | ● |
Instructions | ● |
USB charging port | ● |
Compliance with EU Standards
The EC-JLII150 electric cargo tricycle has an EEC certificate, ensuring it meets the strict standards of EU countries. This certification guarantees the vehicle's safety, reliability, and environmental performance.
Powerful and Efficient Motor
The EC-JLII150 is equipped with a 72V1000W motor and control system, providing powerful performance and efficient operation. The robust motor ensures smooth and reliable running even under heavy loads, making it an ideal choice for various cargo needs.
Spacious Cargo Box
The EC-JLII150 features a cargo box measuring 1500×1100×330 mm, offering ample space for transporting various goods. This spacious cargo box design accommodates multiple types of cargo, ensuring versatility and practicality.
Versatile Backrest Design
The EC-JLII150 offers both single and double backrest options. The double backrest can be folded down to serve as an additional seat inside the cargo box, providing flexibility and comfort for passengers.
Load Capacity and Speed Options
The vehicle has a rated load capacity of 300 kg, with a top speed option of either 25 km/h or 35 km/h, and a maximum climbing slope of ≤20%. These specifications make the EC-JLII150 adaptable to different use scenarios, whether requiring slow, safe transport or faster deliveries.
Advanced Braking and Safety Features
The EC-JLII150 is equipped with front disc brakes and rear drum brakes, ensuring reliable and effective braking performance. The reverse light enhances safety when reversing, and the high/low-speed function allows the driver to select the appropriate speed for different driving conditions.
Modern Instrumentation and Convenience Features
The LCD dashboard displays real-time vehicle information such as speed, battery level, and mileage, keeping the driver informed about the vehicle's status at all times. The USB phone charging feature provides a convenient way to charge phones, ensuring connectivity and accessibility.
Summary
In summary, the EC-JLII150 electric cargo tricycle is a versatile and efficient solution for cargo transportation. With its EEC certification, powerful 72V1000W motor, spacious cargo box, and advanced safety features, it offers a reliable and compliant choice for both urban and rural environments. The adjustable speed settings, comfortable seating options, and modern dashboard make it an ideal choice for businesses and individuals seeking a dependable cargo vehicle. Choose the EC-JLII150 to meet your cargo needs and experience unparalleled performance and versatility.
