Specification
Model | FD250 | ||
Features | Rated Load | Kg | 25000 |
Load Center | mm | 1220 | |
Wheelbase | mm | 4400 | |
Weight | Weight | kg | 33500 |
Chassis | Tire Specs:Front | 14.00-24 | |
Tire Specs:Rear | 14.00-24 | ||
Tires Qty,front/rear(X-dreve wheels) | 4/2 | ||
Wheel tread:Front | mm | 2220 | |
Wheel tread:Rear | mm | 2300 | |
Dimensions | Mast/carriage tilt angle(front/rear) | Degree(°) | 6/12 |
Mast height(fork lowering) | mm | 3970 | |
Mast lifting height | mm | 4000 | |
Max.height | mm | 5940 | |
height to head guard(height to cab) | mm | 3480 | |
Overall height(with forks) | mm | 9040 | |
Fork front verticaal sueface to the rear end of the vehicle | mm | 6640 | |
Overall width | mm | 3060 | |
Fork dimension | mm | 2400*280*105 | |
Fork carriage width | mm | 3000 | |
Mast min ground(with load) | mm | 350 | |
Wheelbase center min ground(with load) | mm | 420 | |
Min.turning Radius | mm | 6480 | |
Travel speed(with load/without load) | km/h | 25/30 | |
Front overhang | mm | 1010 | |
Rear overhang | mm | 1220 | |
Performance | Max.lifting speed(with load/without load) | mm/s | 260/270 |
Traction | KN | 160 | |
Gradeability(with load/without load) | % | 20/22 | |
Engine | Manufacture | WeiChai Engine | |
Model | WD10G220E21 | ||
Rated Output | (Kw) | 162 | |
Optional | cummins | ||
6CTA8.3-C215-II | |||
Rated Output | (Kw) | 160 | |
Cylinder No | 6 | ||
Others | Transmission gears(Front/rear) | 2/1 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
