Specification
Bucket capacity | 0.4m³ |
Rated load | 800 kg |
Overall dimension | 4800*1700*2600mm |
Operating weight | 2800 kg |
Max. dumping height | 2100 mm |
Max. dumping distance | 700 mm |
Engine | Xichai 490 |
Cylinder number | 4-cylinders |
Rated power | 33KW (44.88HP) |
Steering type | Full-hydraulic, articulated |
Torque converter type | Automatic, hydraulic converter |
Gear shift | 2 forward, 2 reverse |
Max. speed | 25 km/h |
Axle | 4WD, 130 |
Tyre size | 31x15.5-15 |
Service brake | Oil drum brake on 4 wheels |
Parking brake | Hand operated drum brake |
Operating type | Mechanical single joystick |
Optional operating type | Pilot control |
Optional configuration | Air conditioner, rearview camera etc. |
Optional attachment | Quick hitch, fork, log grapple etc. |
Package | 1 unit in 1*20GP Container 3 units in 1*40HQ Container |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
