Specification
Model | Unit | LTB09 |
Performance parameter | ||
Self Weight | kg | 882kg |
Bucket capacity | m³ | 0.02 |
Working device mode | Backhoe | |
Power mode | Lithium battery | |
Lithium battery capacity | V/Ah | 72v/135ah |
Battery weight | KG | 100kg |
Operating hours | H | >12H |
Whether to support fast charge | support | |
Full charge time | H | 8H/4H/1H |
Motor Power | KW | 4KW |
Driving speed | km/h | 0-6km/h |
Power consumption per hour | About 1 kWh per hour | |
Decibels within 1 meter | dBA | <55 |
Dimensions | Unit | |
Wheel base | mm | 450 |
Track ground length | mm | 1150 |
Platform ground clearance | mm | 380 |
Width of chassis | mm | 730 |
Width of track | mm | 150 |
Overall length | mm | 2200 |
Overall height | mm | 1880 |
Operating range | Unit | |
Max. digging radius | mm | 2050 |
Max. digging depth | mm | 1400 |
Max. digging height | mm | 2350 |
Max. dumping height | mm | 1600 |
Min. gyration radius | mm | 1100 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
- Адрес: No. 506, Xinglinwan Road, Jimei District, Xiamen City, Fujian Province, Xiamen, Fujian, CN
With the mission of making the world greener, LTMG has focused on the construction machinery industry for more than 20 years. From R&D and production to reaching global customers, LTMG has always been quality-oriented and excellent service, conveying the power of China's machinery manufacturing to the world
